Powerhobby B45 Aluminum Digital Smart Micro Servo / Winch

Smart Function Feature -Available to change the firmware for different usage, requires Powerhobby USB.

Default settings out the package is for a winch servo

Features:

• High-Performance Digital Micro Servo
• High Precision Metal Gears
• High-Quality Coreless Motor
• Dual Ball Bearing
• Full CNC Aluminium Housing
• Ideal for 1/24 Scale RC Monster Car, SCX10.3， SCX24, Airplane, and 450 Class Helicopter Tail and Swashplate, etc.

Specifications:

Operating Voltage: 4.8-8.4V

Operating speed: 0.11sec/60°@ 6.0V
Operating speed: 0.09sec/60°@ 7.4V
Operating speed: 0.08sec/60°@ 8.4V

Stall Torque: 5.8 kg-cm (80 oz-in) @ 6.0V
Stall Torque: 6.8 kg-cm (95 oz-in) @ 7.4V
Stall Torque: 7.5 kg-cm (104oz-in) @ 8.4V

Gear: Steel + Copper
Motor: Coreless
Size: 23*12*27.5mm (0.90 x 0.47 x 1.08 in)
Weight: 21g

Includes:

• Servo + hardware
